ATEN DisplayPort HDBaseT-Lite Extender 4K/40m;1080p/70m
ATEN DisplayPort HDBaseT-Lite Extender 4K/40m;1080p/70m, 4096 x 2160 pixels, AV transmitter & receiver, 70 m, Wired, Black, HDCP
Availability: In stock
ATEN DisplayPort HDBaseT-Lite Extender 4K/40m;1080p/70m. Type: AV transmitter & receiver, Maximum resolution: 4096 x 2160 pixels, Cable types supported: Cat5e, Cat6, Cat6a. Connectivity technology: Wired. Operating voltage (transmitter): 5 V, Operating voltage (receiver): 5 V, Power consumption (TX): 2.84 W. Weight: 750 g, Receiver dimensions (WxDxH): 94.2 x 66 x 29 mm, Receiver weight: 270 g. Package width: 59 mm, Package depth: 239 mm, Package height: 160 mm
Specifications
| Type | AV transmitter & receiver |
| Maximum resolution | 4096 x 2160 pixels |
| Cable types supported | Cat5e, Cat6, Cat6a |
| Maximum transfer distance | 70 m |
| LED indicators | Yes |
| Supported video modes | 1080p |
| Supported graphics resolutions | 3840 x 2160, 4096 x 2160 |
| Bandwidth | 297 MHz |
| HDCP | Yes |
| Material | Metal |
| Rack mounting | Yes |
| Plug and Play | Yes |
| Impedance | 100 Ω |
| HDCP version | 1.4 |
| Product colour | Black |
| HDBaseT certified | Yes |
| Connectivity technology | Wired |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| HDBaseT port | Yes |
| DisplayPorts in | 1 |
| DisplayPorts out | 1 |
| DC-in jack | Yes |
| Operating voltage (transmitter) | 5 V |
| Operating voltage (receiver) | 5 V |
| Power consumption (TX) | 2.84 W |
| Power consumption (RX) | 5.72 W |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
| Weight | 750 g |
| Receiver dimensions (WxDxH) | 94.2 x 66 x 29 mm |
| Receiver weight | 270 g |
| Transmitter dimensions (WxDxH) | 94.2 x 66 x 29 mm |
| Transmitter weight | 240 g |
| Package width | 59 mm |
| Package depth | 239 mm |
| Package height | 160 mm |
| Package weight | 855 g |
| AC adapter included | Yes |
| Manual | Yes |
| Master (outer) case width | 250 mm |
| Master (outer) case length | 325 mm |
| Master (outer) case height | 175 mm |
| Master (outer) case gross weight | 4.85 kg |
| Master (outer) case net weight | 3.75 kg |
| Products per master (outer) case | 5 pc(s) |
